Question#1

Refer to the exhibit.

An engineer must troubleshoot a connectivity issue impacting the redistribution of the subnet 172.16.2.48/28 into the OSPF domain.
Which configuration on router R1 advertises this subnet into the OSPF domain?

A. R1(config)#route-map CCNP permit 10 R1(config-route-map)#match route-type internal R1(config-router)#router ospf 10 R1(config-router)#redistribute eigrp 100 subnets route-map CCNP

B. R1(config)#route-map CCNP permit 10 R1(config-route-map)#match route-type level-2 R1(config-router)#router ospf 10 R1(config-router)#redistribute eigrp 100 subnets route-map CCNP

C. R1(config)#route-map CCNP deny 10 R1(config-route-map)#match tag 200 R1(config)#route-map CCNP permit 10 R1(config-router)#router ospf 10 R1(config-router)#redistribute eigrp 100 subnets route-map CCNP

D. R1(config)#route-map CCNP permit 10 R1(config-route-map)#match tag 200 R1(config-route-map)#exit R1(config-router)#router ospf 10 R1(config-router)#redistribute eigrp 100 subnets route-map CCNP

Question#2

How is the LDP router ID used in an MPLS network?

A. The MPLS LOP router ID must match the IGP router I

B. If not configured, the operational physical interface is chosen as the router ID oven d a loopback is configured.

C. The loopback with the highest IP address is selected as the router ID

D. The force keyword changes the router ID to the speeded address without causing any impact.

Question#3

Refer to the exhibit.

The network operation team observes a traffic forwarding issue between R2 and R3:
✑ Ping and traceroute of loopback IP address from R2 to R3 is successful.
✑ iBGP peering in AS 65101 and AS 65201 is up.
Which configuration resolves the issue?

A. Configure MD5 password authentication on R2.

B. Advertise R2 and R3 loopback IPs in AS 65101 and AS 65201.

C. Remove MD5 password authentication on R3.

D. Set up eBGP multihop on R2 and R3 routers.

Question#4

Which two protocols are used by a P router to transfer VPN traffic between PE routers in an MPLS network? (Choose two.)

A. BGP

B. OSPF

C. MP-BGP

D. LDP

E. RSVP

Question#5

Refer to the exhibit.

The network engineer configured the summarization of the RIP routes into the OSPF domain on R5 but still sees four different 172.16.0.0/24 networks on R4.
Which action resolves the issue?

A. R5(config)#router ospf 1 R5(config-router)#no area R5(config-router)#summary-address 172.16.0.0 255.255.252.0

B. R4(config)#router ospf 99 R4(config-router)#network 172.16.0.0 0.255.255.255 area 56 R4(config-router)#area 56 range 172.16.0.0 255,255.255.0

C. R4(config)#router ospf 1 R4(config-router)#no area R4(config-router)#summary-address 172.16.0.0 255.255.252.0

D. R5(config)#router ospf 99 R5(config-router)#network 172.16.0.0 0.255.255.255 area 56 R5(config-router)#area 56 range 172.16.0.0 255.255.255.0

Explanation:
Area 36 is a NSSA so R5 is an ASBR so we can summarize external routes using the “summary address”
command. The command “area area-id range” can only be used on ABR so it is not correct.
The summarization must be done on the ASBR which is R5, not R4 so the correct answer must be started with “R5(config)#router ospf 1”.
Note: The “no area” command is used to remove any existing “area …” command (maybe “area 56 range …” command).
range …” command).
